Welcome to the Fluke 117 Instruction Manual. This guide provides essential information for safe and effective use of your digital multimeter. Read it carefully to ensure optimal performance and compliance with safety standards.
1.1 Overview of the Fluke 117 Multimeter
The Fluke 117 is a true-rms digital multimeter designed for commercial electricians. It measures AC/DC voltage‚ current‚ resistance‚ capacitance‚ and frequency with precision. Featuring a 6000-count display and a CAT III 600V safety rating‚ it ensures reliable performance in demanding environments. The multimeter includes advanced functions like VoltAlert non-contact voltage detection‚ Auto-V/LoZ‚ and AC mV measurements‚ making it a versatile tool for troubleshooting electrical systems. Its compact design and user-friendly interface enhance efficiency and accuracy in various applications.
1.2 Importance of Reading the Manual
Reading the Fluke 117 manual is crucial for safe and effective use of the multimeter. It provides detailed instructions for operating modes‚ safety precautions‚ and troubleshooting. Understanding the manual ensures accurate measurements‚ prevents equipment damage‚ and helps users avoid potential hazards. It also outlines warranty terms and maintenance tips‚ maximizing the tool’s performance and longevity. By following the guidelines‚ users can optimize their experience and ensure compliance with safety standards.
1.3 Safety Precautions and Warnings
The Fluke 117 manual emphasizes critical safety precautions to prevent injury or equipment damage. Always follow CAT III 600V safety ratings‚ use correct test leads‚ and avoid hazardous conditions. Warning statements identify risks of bodily harm‚ while caution statements highlight potential damage to the meter. Proper handling and storage are essential to maintain functionality and safety. Adhering to these guidelines ensures safe operation and protects both the user and the device from harm. Compliance is mandatory for optimal performance and user protection.
Product Specifications
The Fluke 117 is a CAT III 600V true-rms multimeter designed for precise measurements of voltage‚ current‚ resistance‚ and more. Its 6000-count display ensures accuracy and reliability.
2.1 Key Features of the Fluke 117
The Fluke 117 features a 6000-count LCD display‚ true-rms measurement‚ and a built-in VoltAlert non-contact voltage detector. It includes Auto-V/LoZ for preventing false readings‚ diode testing‚ and frequency measurement capabilities. The multimeter is compact‚ lightweight‚ and powered by a single 9V alkaline battery. Designed for CAT III 600V environments‚ it ensures safe and accurate measurements in various industrial and commercial settings‚ making it a versatile tool for electricians and technicians.
2.2 Technical Specifications
The Fluke 117 weighs 550 grams‚ with dimensions of 167 mm (height)‚ 84 mm (width)‚ and 46 mm (depth). It operates using a single 9V alkaline battery‚ offering up to 400 hours of battery life. The multimeter features a 6000-count LCD display and a bar graph for enhanced readability. It supports CAT III 600V safety rating‚ ensuring safe measurements in industrial environments. Additional specs include Min/Max recording and a compact design for portability and ease of use in various settings.
2.3 Compliance and Certification
The Fluke 117 meets international safety standards with a CAT III 600V rating‚ ensuring safe operation in industrial environments. It complies with IEC standards and is certified for professional use in residential‚ commercial‚ and industrial settings. The multimeter is backed by a 3-year warranty‚ reflecting Fluke’s commitment to quality and reliability. The manual is available in multiple languages‚ including English‚ making it accessible for global users. This certification ensures the device’s accuracy and durability for electrical measurements worldwide.
Safety Information
This section outlines essential safety guidelines for using the Fluke 117. Adhere to all warnings and cautions to prevent injury or damage. Proper handling and storage are emphasized to ensure safe operation and longevity of the device.
3.1 General Safety Guidelines
Always follow general safety guidelines when using the Fluke 117. Ensure correct probe connections and avoid live circuits without proper insulation. Use the multimeter only as specified in the manual to prevent electric shock or damage. Keep the device away from extreme temperatures and moisture. Regularly inspect the probes and leads for wear. Store the multimeter in a protective case when not in use to maintain its condition and ensure accurate measurements. Never ignore safety warnings provided in the manual.
3.2 Understanding Warning and Caution Statements
Warning statements in the Fluke 117 manual highlight potential hazards that could cause bodily harm or death‚ such as electric shock. Caution statements address actions that may damage the multimeter or the equipment under test. Always adhere to these guidelines to ensure safe operation and prevent accidents. Ignoring warnings or cautions can lead to serious consequences‚ so review them carefully before performing any measurements or maintenance tasks.
3.3 Proper Handling and Storage
Proper handling and storage are crucial to maintain the accuracy and longevity of the Fluke 117. Avoid exposing the multimeter to extreme temperatures‚ moisture‚ or physical stress. Clean the device with a soft cloth and avoid harsh chemicals. Store the multimeter in a protective case to prevent damage. When not in use for extended periods‚ remove the battery to prevent corrosion. Ensure the storage area is dry and free from contaminants to maintain optimal performance and reliability over time.
Getting Started
Begin by unpacking and verifying all components‚ then install the battery. Familiarize yourself with the multimeter’s controls and settings. Proceed to initial configuration for accurate measurements.
4.1 Unpacking and Inventory
When you unpack your Fluke 117‚ ensure all components are included: the multimeter‚ test leads‚ holster‚ and user manual; Verify each item for damage or defects. This ensures you have everything needed for proper operation. Check the multimeter’s display for clarity and functionality. Familiarize yourself with the accessories provided to maximize your tool’s utility. Proper inventory ensures readiness for immediate use.
4.2 Battery Installation and Maintenance
Open the battery door on the Fluke 117 and insert the 9V alkaline battery‚ ensuring correct polarity. Close the door securely. The multimeter features a low-battery indicator‚ alerting you when replacement is needed. Avoid using mixed or rechargeable batteries for optimal performance. Regularly inspect the battery compartment for corrosion and clean it if necessary. Replace the battery promptly when the indicator appears to prevent data loss during measurements.
4.3 Initial Setup and Configuration
Before using the Fluke 117‚ ensure the battery is installed correctly. Turn on the multimeter and verify all functions operate properly. Familiarize yourself with the dial and button controls. Set the display to your preferred mode and adjust settings like auto-ranging if needed. Always start with the highest range for unknown measurements. Read the manual to understand advanced features like Auto-V/LoZ for accurate voltage readings. Proper setup ensures reliable performance and precise measurements.
Operating the Fluke 117
Select the desired measurement mode using the rotary dial. Use VoltAlert for non-contact voltage detection or Auto-V/LoZ for accurate voltage readings. Always apply probes correctly for precise results.
5.1 Basic Measurement Modes
The Fluke 117 offers essential measurement modes for voltage‚ current‚ resistance‚ and continuity. For voltage‚ select the appropriate AC or DC range. Current measurements require proper probe placement in series. Resistance mode provides accurate ohms readings‚ while continuity testing emits a beep for intact circuits. These modes ensure versatility for various electrical tasks‚ making the Fluke 117 a reliable tool for professionals and DIYers alike.
5.2 Using the VoltAlert Non-Contact Voltage Detector
The Fluke 117 features VoltAlert technology for non-contact voltage detection. To use this function‚ select VoltAlert mode and hold the multimeter near the conductor. A bright LED and audible beep indicate the presence of voltage. This feature enhances safety by quickly identifying live circuits without physical contact. It operates effectively on voltages between 40V and 600V AC‚ providing a reliable way to verify the absence or presence of voltage in electrical systems before starting work.
5.3 Auto-V/LoZ and AC mV Functions
The Fluke 117 offers Auto-V/LoZ and AC mV functions for precise measurements. Auto-V/LoZ automatically selects voltage or low impedance mode to prevent false readings. The AC mV function measures AC signals in millivolts‚ ideal for audio equipment and low-level AC sources. These advanced features enhance accuracy and efficiency‚ ensuring reliable results in various applications. Use the dial to select the appropriate mode and follow on-screen prompts for optimal performance.
Advanced Features
The Fluke 117 includes advanced features like diode testing‚ frequency measurement‚ and min/max recording. These functions enhance diagnostic capabilities‚ enabling precise troubleshooting and data logging for efficient problem-solving.
6.1 Diode Testing
The Fluke 117 offers a built-in diode test function‚ enabling users to verify diode integrity. By setting the dial to the diode symbol‚ the multimeter applies a test voltage and measures forward voltage drop. An open circuit indicates a faulty diode‚ while a low voltage reading confirms proper operation. This feature simplifies troubleshooting in electronic circuits‚ ensuring accurate and reliable results. Regular diode testing helps maintain circuit functionality and prevents potential system failures.
6.2 Frequency Measurement
The Fluke 117 allows precise frequency measurement‚ essential for diagnosing electrical and electronic systems. Set the dial to the Hz mode‚ select the appropriate range‚ and connect the probes to the circuit. The multimeter accurately measures frequency in hertz‚ supporting AC signals up to 20 kHz. This feature is particularly useful for validating motor drives‚ audio equipment‚ and other cyclic systems. Regular frequency checks ensure system performance and prevent potential malfunctions in industrial and commercial environments;
6.3 Min/Max Recording
The Fluke 117 features Min/Max Recording‚ which captures the minimum and maximum readings during measurement. This function is ideal for detecting fluctuations in voltage‚ current‚ or frequency. To activate‚ press the MIN/MAX button before or during measurement. The display will show the current reading‚ min‚ and max values simultaneously. This feature is particularly useful for identifying intermittent issues in electrical systems. Use the HOLD button to pause measurements for detailed analysis‚ ensuring accurate troubleshooting and system optimization.
Calibration and Maintenance
Regular calibration ensures accuracy. Check calibration interval and use authorized service if needed. Proper maintenance‚ like cleaning and battery checks‚ maintains performance and extends lifespan.
7.1 Calibration Procedures
Calibration is essential for ensuring the accuracy of your Fluke 117 multimeter. Follow these steps:
- Refer to the calibration information manual for specific adjustment procedures.
- Use only Fluke-authorized calibration tools and procedures.
- Adjustments should be performed by trained personnel to avoid damaging the device.
- After calibration‚ verify performance by measuring known values.
- Calibration intervals are typically every 12 months unless specified otherwise.
Regular calibration ensures reliable measurements and compliance with safety standards.
7.2 Regular Maintenance Tips
Regular maintenance ensures optimal performance of your Fluke 117 multimeter. Replace the 9V alkaline battery when the low-battery indicator appears. Clean the probes and input jacks with a soft cloth and mild solvent to prevent corrosion; Store the multimeter in a dry‚ cool place to protect it from environmental damage. Check for firmware updates and install them as needed to maintain accuracy. Follow these steps to extend the lifespan and reliability of your device.
7.4 Troubleshooting Common Issues
Common issues with the Fluke 117 include low battery warnings‚ inaccurate readings‚ or non-responsive screens. Ensure the battery is fresh and properly installed. Clean the probes and input jacks to eliminate corrosion. For inaccurate readings‚ check the range selection and verify probe connections. If issues persist‚ refer to the troubleshooting guide in the manual or contact Fluke support for assistance. Regular calibration and updates can also resolve many operational problems.
Technical Support and Resources
For assistance‚ contact Fluke support at 1-888-99-FLUKE (USA) or 1-800-36-FLUKE (Canada). Visit the official website for manuals‚ FAQs‚ and troubleshooting guides to resolve common issues quickly.
8.1 Contacting Fluke Support
For technical assistance‚ contact Fluke support at 1-888-99-FLUKE (USA) or 1-800-36-FLUKE (Canada). International users can reach support at 31 402-675-200. Visit the official Fluke website for additional resources‚ including FAQs‚ manuals‚ and troubleshooting guides. Ensure to have your product serial number ready for efficient support. Fluke’s dedicated team is available to address your inquiries and provide solutions promptly. Online resources are accessible 24/7 for quick reference and problem-solving.
8.2 Accessing Online Manuals and Updates
Access the Fluke 117 manual and updates online through the official Fluke website or platforms like Manuals.co.uk and Manua.ls. These resources offer free PDF downloads of the 28-page user manual‚ ensuring you always have the latest version. The manual is available in English and includes detailed instructions‚ safety guidelines‚ and technical specifications. Use the search bar on these sites to quickly find the Fluke 117 manual by entering the brand and product name. Regularly check for updates to stay informed about new features and improvements.
8.3 FAQs and Common Questions
Frequently Asked Questions about the Fluke 117 include inquiries about its battery type‚ CAT III 600V rating‚ and weight. Users also ask about its dimensions (84mm width‚ 46mm depth‚ 167mm height) and warranty details (3-year limited warranty). Many seek clarification on diode testing and frequency measurement capabilities. Additional questions involve proper handling and storage tips to maintain accuracy. These FAQs provide quick solutions to common user queries‚ ensuring optimal use of the multimeter.
Warranty and Liability Information
The Fluke 117 is covered by a 3-year limited warranty. Fluke is not liable for damages resulting from improper use or non-compliance with safety guidelines.
9.1 Warranty Details
The Fluke 117 multimeter is covered by a 3-year limited warranty starting from the purchase date. This warranty ensures the product is free from defects in material and workmanship. During this period‚ Fluke will repair or replace defective units at their discretion. The warranty does not cover damages caused by misuse‚ unauthorized modifications‚ or failure to follow operating instructions. For warranty service‚ contact Fluke directly.
9.2 Limitation of Liability
Fluke Corporation shall not be liable for indirect‚ incidental‚ or consequential damages arising from the use of the Fluke 117 multimeter. Liability is limited to the repair or replacement of defective units under the warranty terms. Damages caused by misuse‚ unauthorized modifications‚ or failure to adhere to instructions are not covered. The company’s liability is restricted to the product’s purchase price‚ ensuring protection for the buyer within specified legal boundaries.
Environmental and Regulatory Compliance
The Fluke 117 complies with global environmental standards‚ promoting eco-friendly design and responsible recycling. It adheres to regulatory requirements‚ ensuring safe disposal and minimizing environmental impact.
10.1 Eco-Friendly Design
The Fluke 117 is crafted with eco-friendly materials‚ ensuring minimal environmental impact. Its energy-efficient design reduces power consumption‚ while recyclable components promote sustainability. Lightweight and compact‚ it minimizes material usage without compromising performance. Fluke’s commitment to environmental responsibility is evident in its adherence to global sustainability standards‚ making the 117 an eco-conscious choice for professionals. This approach aligns with modern environmental regulations‚ ensuring responsible manufacturing and disposal practices.
10.2 Recycling Information
Fluke encourages responsible disposal and recycling of the 117 multimeter. Return the device to authorized recycling centers or participate in Fluke’s sustainability programs. Proper recycling ensures hazardous materials are safely managed; Components like batteries and electronics are recyclable‚ reducing environmental impact. Check local regulations for specific guidelines on e-waste disposal. Fluke’s commitment to sustainability supports eco-friendly practices throughout the product lifecycle.
Congratulations! You’ve completed the Fluke 117 manual. This guide has equipped you to use the multimeter effectively‚ ensuring safety and accuracy in electrical measurements. Master its features for professional success.
11.1 Final Tips for Effective Use
- Familiarize yourself with all features like Auto-V/LoZ and VoltAlert to enhance efficiency.
- Always store the multimeter in a protective holster to prevent damage.
- Check test leads regularly for wear and tear to ensure accurate readings.
- Use the correct ranges for measurements to avoid potential errors.
- Monitor battery life and replace it promptly to maintain reliability.
- Refer to the manual for troubleshooting common issues quickly.
- Keep the multimeter updated with the latest calibration for precision.
- Follow safety guidelines to ensure safe and effective operation.
11.2 Continuous Learning and Improvement
To maximize the potential of your Fluke 117‚ commit to continuous learning. Explore advanced features like frequency measurement and min/max recording to refine your skills. Regularly review the manual to discover new functionalities and stay updated with the latest firmware. Engage in hands-on practice to build confidence and efficiency. Join forums or training sessions to share insights and gain tips from experienced users. Continuous improvement ensures you remain proficient and adaptable in your work.
